Stainless Steel 310 Ball Valve

Home > Stainless Steel > Stainless Steel 310 Ball Valve

Malik Tube Fittings is a reputable manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in top-notch Stainless Steel 310 Ball Valves that are perfect for high-temperature and corrosive environments. These valves are designed to offer precise shut-off, smooth operation, and leak-proof performance, making them a go-to choice for critical flow control applications. Thanks to their exceptional resistance to oxidation and corrosion, Stainless Steel 310 Ball Valves find extensive use in industries like oil and gas, petrochemicals, chemical processing, power generation, and marine operations. Their sturdy design guarantees a long service life, reliability, and safe operation, even in the toughest industrial settings.

Stainless Steel 310 Instrumentation Ball Valve Manufacturer in Riyadh, Stainless Steel DIN 1.4841 Compression Ball Valve in Dammam, SS UNS S31000 Hydraulic Ball Valve Supplier in Jeddah, X5CrNi18-10 Stainless Steel High Pressure Ball Valve Price List in Riyadh, 310 Stainless Steel 2 Way Ball Valve Price in Dammam, DIN 1.4841 SS 3 Way Ball Valve in Riyadh, Saudi Arabia, UNS S31000 Stainless Steel 4 Way Ball Valve Price in Al jubail, 310 Stainless Steel 5 Way Ball Valve Supplier in Jeddah

Stainless steel 310 ball valves are made of an alloy of 25% chromium and 20% nickel, for excellent resistance to oxidation and corrosion at high temperatures (up to 1150°C) Mechanical properties include 515 MPa tensile strength, 205 MPa yield strength and 40 % elongation. These valves provide high strength, good weldability and toughness even at cryogenic temperatures. Their main advantage is that they resist exceptional heating cycles, making them ideal for chemicals and heating fuels

Stainless Steel 310 Ball Valve Specifications

VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Stainless Steel 310 Ball Valve Chemical Composition

SS Grade		Mn	Si	C	N	Cr	S	P	Mo	Ni
310	minimum maximum	– 2.00	– 1.50	– 0.25	–	24.0 26.0	– 0.030	– 0.045	–	19.0 22.0
310S	minimum maximum	– 2.00	– 1.50	– 0.08	–	24.0 26.0	– 0.030	– 0.045	–	19.0 22.0

Stainless Steel 310 Ball Valve Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Rockwell B (HR B) max	Brinell (HB) max
Stainless steel 310S Valves	515	205	40	95	217
Stainless Steel 310 Valves	515	205	40	95	217

Stainless Steel 310 Ball Valve Equivalent

STANDARD	UNS	WERKSTOFF NR.	EN	BS	JIS
SS 310	S31000	1.4845	X8CrNi25-21	310S16	SUS 310S

Top Stainless Steel 310 Ball Valve Manufacturing Company in Riyadh

At Malik Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel 310 Ball Valve in Riyadh, Saudi Arabia. Our advanced manufacturing facilities, strategically positioned in the Saudi Arabia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel 310 Ball Valve

Stainless Steel 310 Instrumentation Ball Valve Price in Al jubail, UNS S31000 Stainless Steel Compression Ball Valve Supplier in Jeddah, X5CrNi18-10 Stainless Steel Hydraulic Ball Valve Manufacturer in Riyadh, DIN 1.4841 Stainless Steel High Pressure Ball Valve in Dammam, 310 Stainless Steel 2 Way Ball Valve Supplier in Jeddah, UNS S31000 Stainless Steel 3 Way Ball Valve in Riyadh, Saudi Arabia, DIN 1.4841 Stainless Steel 3 Way Ball Valve Price List in Riyadh, 310 SS 5 Way Ball Valve Price in Dammam

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel 304 Ball Valve in Riyadh, Saudi Arabia

Malik Tube Fittings is a leading supplier and stockist of premium Stainless Steel 310 Ball Valve in Riyadh, Saudi Arabia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel 310 Ball Valves Uses

Stainless Steel 310 Ball Valves are widely utilized in industries that demand reliable shut-off and control of fluids and gases. You’ll often find them in chemical plants, refineries, petrochemical facilities, power generation systems, furnaces, and marine operations. Their ability to endure extreme temperatures and corrosive conditions makes them ideal for continuous industrial use. With Stainless Steel 310 Ball Valves, you can count on safe and efficient operation in instrumentation lines, pipelines, and process systems, delivering dependable performance and requiring minimal maintenance in even the most demanding applications.
