Inconel 718 Ball Valve

Home > Inconel >Inconel 718 Ball Valve

Malik Tube Fittings, located in Riyadh, Saudi Arabia, has built a solid reputation as a manufacturer and supplier of top-notch Inconel 718 ball valves. These valves are crafted for outstanding strength, corrosion resistance, and reliable performance, even in the toughest industrial settings. Each Inconel 718 ball valve is designed to meet international standards, ensuring precise flow control, leak-proof operation, and a long lifespan. Malik Tube Fittings serves a variety of industries, including aerospace, oil and gas, chemical processing, marine, and power generation, providing robust ball valves that blend innovative design, high-quality materials, and consistent functionality for safe and efficient handling of fluids and gases.

Inconel Instrumentation 718 Ball Valve Manufacturer in Riyadh, DIN 2.4668 Inconel Alloy Compression 718 Ball Valve in Dammam, Inconel Hydraulic 718 Ball Valve Supplier in Jeddah, Inconel High Pressure 718 Ball Valve Price List in Riyadh, Inconel 2 Way 718 Ball Valve Price in Dammam, Inconel Alloy 3 Way 718 Ball Valve in Riyadh, Saudi Arabia, Inconel 4 Way 718 Ball Valve Price in Al jubail, Inconel 5 Way 718 Ball UNS N06718 Valve Supplier in Jeddah, Inconel High Pressure 718 Ball Valve Price List in Ras Al Khair

The Inconel 718 ball valves from Malik Tube Fittings are made from a high-strength nickel-chromium alloy, enhanced with molybdenum, niobium, and titanium. This combination offers exceptional resistance to oxidation, high-temperature creep, and stress corrosion cracking. With precision-machined balls and seats, these valves guarantee smooth operation, tight sealing, and minimal leakage, even under high-pressure conditions. They boast impressive mechanical properties, including high tensile and yield strength, excellent fatigue resistance, and durability in extreme pressure and temperature scenarios. Built to withstand harsh environments, these ball valves maintain their structural integrity and reliable performance with minimal maintenance, boosting operational safety and efficiency.

Inconel 718 Ball Valve Specifications

SPECIFICATION	ASTM A494 / ASME SA494 API 602, ASME B16.34, SME B16.5, ASME B16.25, ASME B1.20.1, ASME B16.11, ASME B16.10, BS 5352, DIN3352
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO, DIN , ANSI, API , ASME, AWWA , MSS,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER, COLD WATER, SEA WATER, CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES, POWER GENERATING PLANT, STEEL MANUFACTURING PLANT, MINING INDUSTRIES, CHEMICAL PROCESSING MACHINES, PIPING LINE, PAINT INDUSTRIES, TRUCKS AND TRAILERS , AUTOMATION, AGRICULTURE MACHINES, AEROSPACE & DEFENCE EQUIPMENT,

Inconel 718 Ball Valve Chemical Composition

Ni	Cr	Fe	Mo	Nb+Ta	C	Mn	Si	Ph	S	Ti	Cu	B	Al	Co
Min	50	17	Bal	2.8	4.75	–	–	–	–	–	0.65	–	–	0.20	–
Max	55	21	–	3.3	5.50	0.08	0.035	0.35	0.015	0.015	1.15	0.30	0.0006	0.80	1.00

Inconel 718 Ball Valve Mechanical Properties

0.2% Proof Stress	Tensile Strength	Elongation	Reduction of area	Hardness
MPA	MPA	%	%	HB
Min	Min	Min	Min	Min
1034	1275	12	15	331

Inconel 718 Ball Valve Equivalent

STANDARD	WNR Material Number	UNS	JIS	BS	GOST	AFNOR	EN
718	2.4668	N07718	–	–	–	–	–

Top Inconel 718 Ball Valve Manufacturing Company in Riyadh

At Malik Tube Fittings, we are the largest supplier, manufacturer, and exporter of Inconel 718 Ball Valve in Riyadh, Saudi Arabia. Our advanced manufacturing facilities, strategically positioned in the Saudi Arabia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Inconel 718 Ball Valve

Inconel 3 Way 718 Ball Valve in Riyadh, Saudi Arabia, DIN 2.4668 Inconel Alloy 3 Way 718 Ball Valve Price List in Riyadh, Inconel 5 Way 718 Ball Valve Price in Dammam, Inconel Instrumentation 718 Ball Valve Price in Al jubail, Inconel Compression 718 Ball Valve Supplier in Jeddah, Inconel Hydraulic 718 Ball Valve Manufacturer in Riyadh, Inconel Alloy High Pressure 718 Ball Valve in Dammam, UNS N06718 Inconel 2 Way 718 Ball Valve Supplier in Jeddah

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Inconel 625 Ball Valve in Riyadh, Saudi Arabia

Malik Tube Fittings is a leading supplier and stockist of premium Inconel 718 Ball Valve in Riyadh, Saudi Arabia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Inconel 718 Ball Valve Uses

Inconel 718 ball valves are commonly used to manage the flow of corrosive fluids, gases, and steam in critical applications. You’ll find them in aerospace systems, offshore oil and gas platforms, chemical plants, marine engineering, nuclear facilities, and high-temperature process lines. Their sturdy construction, precise performance, and superior corrosion resistance make them perfect for high-pressure, high-temperature, and highly corrosive conditions. Inconel 718 ball valves are vital components in advanced industrial systems, ensuring safe and efficient operations.
