Hydraulic Ermeto Nut

Home > Hydraulic Ermeto Nut

Malik Tube Fittings stands out as a top manufacturer and supplier in Riyadh, Saudi Arabia, specializing in high-quality Hydraulic Ermeto Nuts. These nuts are expertly crafted to ensure secure, leak-proof connections in hydraulic systems. Designed with precision and built to last, they are perfect for joining tubes and fittings, delivering impressive mechanical strength and dependable performance even under high pressure. Made from premium materials and following international standards, Malik’s hydraulic Ermeto nuts boast corrosion resistance, precise dimensions, and long-lasting reliability. They’re the go-to choice for industrial machinery, automotive hydraulics, oil and gas, and power generation systems, boosting both safety and efficiency.

E0 Nut Supplier in Riyadh, Ermeto Nut Price List in Jeddah, E0 Nut Manufacturer in Al jubail, Ermeto Nut In Dammam, E0 Nut Exporter in Jeddah, Ermeto Nut Manufacturer in Ras Al Khair, E0 Nut In Riyadh, Saudi Arabia.

Hydraulic Ermeto Nuts are generally constructed from high-strength carbon steel, alloy steel, or stainless steel, providing outstanding tensile and yield strength to handle high-pressure hydraulic tasks. With precision-machined threads and a sturdy build, they guarantee leak-tight connections and resist loosening due to vibrations. Mechanically, these nuts show excellent fatigue resistance, durability through repeated hydraulic cycles, and stability under thermal and mechanical stress. Their combination of corrosion resistance and precise dimensions makes hydraulic Ermeto nuts a trustworthy option for long-term use in challenging industrial, mobile, and offshore hydraulic settings.

Hydraulic Ermeto Nut Specifications

STANDARD	DIN 2353/ ISO 8434-1
MATERIAL	MS, CS, SS 304, SS 304L, SS 316, SS 316L, SS 316TI ( 1.4571), BRASS , COPPER, DUPLEX , SUPER DUPLEX, INCONEL , MONEL, HASTELLOY , 904L, 6MO, TITANIUM, ALUMINUM, ALLOY 20
MATERIAL
SERIES	LL- LOW PRESSURE, L- MEDIUM PRESSURE, S- HIGH PRESSURE
WORKING PRESSURE	(LOW) LL SERIES – 100 BAR
	(MEDIUM)L SERIES – 100 BAR TO 500 BAR
	(HEAVY)S SERIES – 200 BAR TO 800 BAR
SIZE RANGE	LL SERIES – 4LL TO 12LL
	L SERIES – 6L TO 42L
	S SERIES – 6S TO 38S
BODY TYPE	BAR STOCK
SURFACE	CARBON STEEL -TRIVALENT ZINC PLATED, YELLOW PLATTING, BLACK PHOSPHATE,
SURFACE	STAINLESS STEEL – EXPORT BRIGHT FINISH, SHORT BLASTED FINISH, ELECTROPLATED FINISH
TEMPERATURE	STEEL – (-40* C TO 120C) ,STAINLESS STEEL – (-60C TO 400C) BRASS – (-60C TO 175*C)

Top Hydraulic Ermeto Nut Manufacturing Company in Riyadh

At Malik Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Ermeto Nut in Riyadh, Saudi Arabia. Our advanced manufacturing facilities, strategically positioned in the Saudi Arabia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Hydraulic Ermeto Nut

Hydraulic Ermeto Nut Technical Data

Tube O.D. (mm): 8
Size: M 14×1.5
Shape: EO2-Functional nut
Series: Light
Material: Stainless steel
Seal Material: FKM
Product Series: Very light, Light, Heavy
Size: na, M 08×1.0 to M42x2.0
Materials of Construction: Steel/NBR, Steel/FKM, Stainless steel/FKM, Stainless steel/NBR, Steel/Stainless steel/NBR, Steel/Stainless steel/FKM, Steel, Stainless steel, Stainless steel SPH
Seal Material:na, NBR, FKM
Tube Outside Diameter: 6-42 mm
Shape: EO2-Functional nut, EO2-FORM Set for steel and stainless steel tubes, EO2-FORM Set for stainless steel tubes, Nut EO 24° Cone end, Cutting ring, Progressive stop ring, Progressive ring, Sleeve screw for threaded ports acc. to DIN 3854
Maximum Operating Temperature: +250 Steel, +400 Stainless Steel °C, +482 Steel, +752 Stainless Steel °F
Minimum Operating Temperature: -40 (Steel); -60 (Stainless Steel) °C, -40 Steel, -76 Stainless Steel °F
Application: Agriculture Equipment, Automotive Process, Chemical Transfer, Construction Equipment, Fuel transfer, Hydraulic, Manufacturing Equipment, Marine, Material Handling, Mobile Equipment, Oilfield, Packaging, Transportation
Specifications Met: DIN ISO 8434

E0 Nut Exporter in Riyadh, Ermeto Nut Price List in Jeddah, E0 Nut Manufacturer in Al jubail, Ermeto Nut In Dammam, E0 Nut Supplier in Jeddah, Ermeto Nut Manufacturer in Ras Al Khair, E0 Nut In Riyadh, Saudi Arabia.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Hydraulic Ermeto Nut Supplier in Riyadh, Saudi Arabia

Malik Tube Fittings is a leading supplier and stockist of premium Hydraulic Ermeto Nut in Riyadh, Saudi Arabia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Hydraulic Ermeto Nut Uses

Hydraulic ermato nuts are widely used to secure fittings and hoses in hydraulic systems, providing a watertight connection. They provide reliable seals under pressure and temperature conditions, making them ideal for applications in machine, automotive, aerospace and industrial applications The design facilitates installation and removal, and ensures easy to maintain and repair. Furthermore, these nuts can accommodate a variety of container types and sizes, providing versatility in system design. Their durable construction ensures durability and durability, contributing to the efficiency and safety of all water systems.
