Nickel Alloy Condensate Pots

Home > Nickel Alloy >Nickel Alloy Condensate Pots

Malik Tube Fittings stands out as a reliable manufacturer and supplier of Nickel Alloy Condensate Pots in Riyadh, Saudi Arabia, offering top-notch solutions for tough industrial needs. These pots are expertly designed to gather and temporarily store condensate, shielding sensitive instruments from the harsh effects of high-temperature fluids or steam. Crafted from high-quality nickel alloys, they boast exceptional resistance to corrosion, oxidation, and extreme temperatures. Widely utilized in the oil and gas, power generation, chemical, and petrochemical sectors, Nickel Alloy Condensate Pots from Malik Tube Fittings ensure durability, safety, and dependable performance.

Nickel Alloy Type A Condensate Pot with Galvanized Plating Manufacturer Riyadh, Nickel Alloy Condensate Pot Type B Dealer Jeddah, 200 Nickel Alloy Type C Condensate Pot Supplier Al jubail, Nickel Alloy Type A Condensate Pots with 2 Ports Exporter In Dammam, 200 Nickel Alloy Type B Condensate Pot Supplier Ras Al Khair, Alloy 201 Type C Condensate Pot with Zinc Plating Riyadh, Saudi Arabia.

These pots primarily consist of nickel, enhanced with alloying elements like chromium, molybdenum, and iron to boost their mechanical strength and resistance to corrosion. This unique blend provides excellent protection against harsh chemicals, seawater, and both acidic and alkaline environments. On a mechanical level, they deliver high tensile and yield strength, toughness, and thermal stability, making them perfect for extreme pressure and temperature applications. Their metallurgical stability ensures a long service life and reliable performance, even in challenging conditions.

Nickel Alloy Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Types of Nickel Alloy Condensate Pots

Top Nickel Alloy Condensate Pots Manufacturing Company in Riyadh

At Malik Tube Fittings, we are the largest supplier, manufacturer, and exporter of Nickel Alloy Condensate Pots in Riyadh, Saudi Arabia. Our advanced manufacturing facilities, strategically positioned in the Saudi Arabia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Sizing Of Alloy Condensing Pot of Nickel Alloy Instrumentation ManifoldsNickel Alloy Condensate Pots

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Nickel Alloy Type A Condensate Pot with Red Oxide Coated Price in Riyadh, Nickel Alloy Type B Condensate Pots with 3 Ports Supplier in Jeddah, 201 Nickel Alloy Condensate Pots Type C Manufacturer in Al jubail, Alloy 201 Type A Condensate Pots Dealer in Dammam, 201 Nickel Alloy Condensate Pots Type B Supplier And Manufacturer in Ras Al Khair, Nickel Alloy Type C Condensate Pots with 4 Ports Exporter In Riyadh, Saudi Arabia.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Nickel Alloy Condensate Pots Supplier in Riyadh, Saudi Arabia

Malik Tube Fittings is a leading supplier and stockist of premium Nickel Alloy Condensate Pots in Riyadh, Saudi Arabia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the Metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Nickel Alloy Condensate Pots Uses

Nickel Alloy Condensate Pots are essential in industries that demand dependable condensate collection and system protection. In power plants, they safeguard pressure measurement instruments by cooling steam, while the oil and gas sector uses them to shield gauges and transmitters from aggressive fluids. Chemical and petrochemical facilities count on their resistance to corrosive substances, and marine and offshore applications benefit from their seawater resilience. With their strength, versatility, and durability, Nickel Alloy Condensate Pots are a vital part of efficient fluid and steam handling systems.
