Incoloy 800 Ball Valve

Home > Incoloy > Incoloy 800 Ball Valve

Malik Tube Fittings, located in Riyadh, Saudi Arabia, stands out as a trusted manufacturer and supplier of top-notch Incoloy 800 ball valves. These valves are crafted for outstanding strength, heat resistance, and corrosion protection, making them perfect for tough industrial settings. Each Incoloy 800 ball valve is meticulously designed to comply with international standards, ensuring precise flow control, leak-proof performance, and a long-lasting service life. Malik Tube Fittings serves a variety of industries, including chemical processing, oil and gas, petrochemical, marine, and power generation, delivering robust ball valves that blend cutting-edge engineering, high-quality materials, and reliable performance for safe and efficient handling of fluids and gases.

Incoloy Alloy 800 2-Way Ball Valve Supplier in Riyadh, Incoloy 800 Ball Valves Price List in Jeddah, Incoloy 800 3-way Ball Valves Manufacturer in Al jubail, Incoloy 800 Ball Valves In Dammam, Incoloy 800 Instrumentation Ball Valves, Incoloy 800 One-Piece Ball Valves Exporter in Jeddah, Incoloy 800 Instrument Ball Valve Manufacturer in Ras Al Khair, Incoloy 800 Ball Valve in Riyadh, Saudi Arabia.

The Incoloy 800 ball valves from Malik Tube Fittings are constructed from a high-performance nickel-iron-chromium alloy, known for its remarkable resistance to oxidation, carburization, and stress corrosion cracking caused by chlorides. These valves are equipped with precision-machined balls and seats, ensuring smooth operation, tight seals, and minimal leakage even under high-pressure and high-temperature conditions. They boast impressive mechanical properties, including strong tensile and yield strength, excellent creep-rupture resistance, and durability in both reducing and oxidizing environments. Built to withstand harsh operating conditions, these ball valves guarantee structural integrity and dependable functionality with minimal maintenance, enhancing both safety and efficiency in operations.

Incoloy 800 Ball Valve Specifications

SPECIFICATION	ASTM A494 / ASME SA494 API 602, ASME B16.34, SME B16.5, ASME B16.25, ASME B1.20.1, ASME B16.11, ASME B16.10, BS 5352, DIN3352
VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Incoloy 800 Ball Valve Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
800	0.10 max	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60	0.15 – 0.60
800H	0.05 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60	0.15 – 0.60
800HT	0.06 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00	0.15 – 0.60ᴬ	0.15 – 0.60ᴬ

Incoloy 800 Ball Valve Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
800 / 800H / 800HT	7.94 g/cm3	1385 °C (2525 °F)	Psi – 75,000 , MPa – 520	Psi – 30,000 , MPa – 205	30 %

Types of Incoloy 800 Ball Valve

IIncoloy 800 Ball Valve Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN	OR
Incoloy 800	1.4876	N08800	NCF 800	NA 15	ЭИ670	Z8NC32-21	X10NiCrAlTi32-20	XH32T
Incoloy 800H	1.4958 / 1.4876	N08810	NCF 800H	NA 15(H)	ЭИ670	Z8NC33-21	X5NiCrAlTi31-20	XH32T
Incoloy 800HT	1.4859 / 1.4876	N08811	NCF 800HT	NA 15(HT)	ЭИ670	–	X8NiCrAlTi32-21	XH32T

Incoloy 800 Trunnion Ball Valve, Incoloy 800 Flanged Ball Valve, Incoloy Alloy 800 Swing Out Ball Valves Price in Riyadh, UNS N08800 Instrumentation Ball Valve Supplier in Jeddah, Incoloy 800 Lined Ball Valves Manufacturer in Al jubail, Incoloy 800 High Pressure Ball Valves Price in Dammam, Incoloy 800 Three-piece Ball Valves Supplier And Manufacturer in Ras Al Khair, Incoloy 800 Flanged Ball Valve In Riyadh, Saudi Arabia.

Largest Manufacturer and Supplier of Incoloy 800 Ball Valve in Riyadh, Saudi Arabia

At Malik Tube Fittings, we are proud to be the largest supplier, manufacturer, and exporter of Incoloy 800 Ball Valve in Riyadh, Saudi Arabia. Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Saudi Arabia, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Incoloy 800 Ball Valve Uses

Incoloy 800 ball valves are commonly utilized to regulate the flow of corrosive fluids, gases, and steam in critical systems. You’ll find them in petrochemical units, chemical plants, power generation facilities, oil and gas refineries, marine systems, and heat-treatment equipment. Their sturdy construction, exceptional corrosion resistance, and precise sealing capabilities make them perfect for high-pressure, high-temperature, and corrosive service conditions. Incoloy 800 ball valves are vital components in advanced industrial systems, ensuring safe, efficient, and reliable flow control while minimizing downtime.
